Semi-Automatic Round-Product Labeling System
LabelMill Integrated Labeling Solutions combine the LM6000ARS AutoRound platform with the LM4012 hybrid servo drive label applicator to create a semi-automatic labeling solution for pre-printed labels on round products ranging from 0.5 inches to 1 inch OD.
Products are fed from a hopper into a custom carousel drum to support steady production flow. Automatic product sensing helps reduce mis-labeling when a container is missing, while centralized touchscreen controls make system adjustments and operation easier to manage.
The LM6000ARS – LM4012 Semi-Automatic Table Top Label Applicator is engineered for mid- to high-volume production environments where small round containers require consistent pre-printed label application.
Its hopper-fed carousel system supports continuous product loading, while the LM4012 hybrid servo drive applicator delivers labeling speeds up to 1,400 linear inches of web per minute. Label placement accuracy can reach ±1/32 inch when labels are produced to specification and product handling is controlled.
The system combines controlled product handling with automatic product sensing to reduce mis-labeling and wasted labels. A centralized touchscreen interface gives operators convenient access to system settings and parameter adjustments.
The LM6000ARS – LM4012 is designed for mid- to high-volume applications requiring pre-printed labels to be applied to round products.
Typical applications include:
- Applying pre-printed labels to conveyed products
- Applying pre-printed labels to robotically presented products
- Bottles
- Tubes
- Containers
- Round products from 0.5 inches to 1 inch OD
Industries include:
- Automotive
- Bottling
- Cannabis
- Chemical
- Food and Beverage
- Manufacturing
- Pharmaceutical
- Health and Beauty
- Speeds up to 1,400 inches per minute
- Heavy-duty DC drive
- Dynamic motor control
- 12-inch label storage spool standard
- Heavy-duty industrial design
- User-friendly operating software
- Automatic set-up
- Batch counter
- Left- and right-hand designs
- Handheld user interface
- Optional width of 6.5 inches
- System status light tower
- Smart tamp
- Loose-loop interface to thermal printer
- Left- or right-hand models
- Custom systems
Performance
- Labeling speeds up to 1,400 linear inches of web per minute
- Label placement accuracy up to ±1/32 inch when labels are produced to specifications and product handling is controlled
- Heavy-duty 1/8 HP DC drive motor
- Hybrid servo drive label applicator
- Designed for mid- to high-volume production applications
Product Handling
- Designed for round products from 0.5 inches to 1 inch OD
- Product hopper feeds containers into the system
- Custom carousel drum positions products for label application
- Automatic sensing helps prevent mis-labeling when a product is absent
- Supports continuous operator loading
Label Handling
- 12-inch maximum label roll outside diameter
- 3-inch inside diameter core
- Minimum 1/8-inch separation between labels in the running direction
- Minimum label size of 1/2 inch wide × 1/2 inch long
- Maximum label size of 6.5 inches wide × 12 inches long
- Optional label sizes available
Controls & Operation
- Centralized touchscreen control
- User-friendly operating software
- Automatic set-up
- Batch counter
- Handheld user interface
- Dynamic motor control
Labeling Performance
- Labeling Speed: 1,400 linear inches of web per minute standard
- Drive System: Heavy-duty 1/8 HP DC drive motor
- Label Placement: Up to ±1/32″ when labels are produced to specifications and product handling is controlled
Product Capacity
- Round Product Diameter: 0.5″–1″ OD
- Product Handling: Hopper-fed custom carousel drum
- Product Detection: Automatic sensing to help prevent mis-labeling when a product is absent
Label Capacity
- Maximum Label Roll Diameter: 12″ OD
- Core Size: 3″ ID
- Minimum Label Size: 1/2″ W × 1/2″ L
- Maximum Label Size: 6.5″ W × 12″ L
- Minimum Label Separation: 1/8″ in the running direction
- Optional Label Sizes: Available
Product Sensors
- Product Sensors: Photoelectric or dry contact mechanical limit switch
Electrical & Air Requirements
- Electrical: 115 VAC / 60 Hz – 6 Amps
- Air Requirements: 80 PSI / 3 CFM when equipped with tamp, flag, blow, swing, or corner wrap
Machine Specifications
- General Size: 25″ W × 22″ D × 21″ H
- Weight: 60 lbs. with U-arm
Operating Environment
- Temperature: 50°–95°F (10°–35°C)
- Humidity: 15–85% RH, non-condensing
