High-Performance Label Applicator
ALritma is a high-performance pressure-sensitive labeler designed to be integrated into packaging lines in which production speed and reliability are the primary requirements.
ALritma labelers are based on an innovative mechanical structure which matches strength with versatility. It is available in three versions, S, M and L, for label widths up to 4”, 8” and 12″ respectively.
The ALritma label applicator is controlled by a powerful microprocessor with a touch screen display. The most frequently used parameters are displayed via intuitive icons which represent the various functions and provide advanced management, relieving the operator of the need to perform complex mechanical adjustments and noticeably speeding up format changes.
- Pre-dispensing adjustment in tenths of a mm (1/250″)
- Speed adjustment in 0.1 m (4″)/min increments
- Labeling delay adjustment in mm
- Acceleration/deceleration ramp adjustment
- Storage of different label formats
- Automatic recovery of missing labels
- Progressive and countdown piece counter
- Automatic removal of double product detection
- Shift register between product sensor and label application point
- End-of-roll alarm and web break alarm
- Output for connection to other systems.
In addition to sophisticated standard devices, ALritma labelers can be equipped with an array of options to increase their performance and range:
- Hot-foil printing unit
- Supplementary unwinding unit
- Unwinding unit for larger reels up to 400 mm (16″)
- Hot-foil printing unit
- Sensor for transparent material labels
- Pneumatic and air-blow applicators
- Near-end-of-reel sensor
- Correct label application monitoring device
- Non-stop control for sequentially placed applicators
- Automatic speed control, via encoder
- Serial Interface for connection to PC.
Technical specifications ALritma S / M / L
| Label Width Max mm. | 100(S); 200(M); 300(L) |
| Speed (m/min) | 40 (S); 40 (M); 30 (L) |
| Controls | Display touch screen |
| Memory Capacity | 40 formats |
| Machine Body Protection | IP55 |
| Ø Unwind unit | 300 mm |
| Standard Alarms | End Of Roll / Web Break / Drive Open |
| Missing label recovery | Standard |
| Near end of roll check | Optional |
| Pneumatics applicator | Optional |
| Encoder | Optional |
| Transparent label sensor | Optional |
| Coder / TT Printer | Optional |
| Power Supply | 240 V – 50 Hz – 400 W |
| Power Consumption | 400 W |
